Front Door for House Wholesaler in China | Entry & Entrance Door Specs

ROGENILAN manufactures aluminum front doors for house projects from a 12,000 m² facility in Foshan, China. This page lists factory pricing, profile specifications, performance ratings, hardware systems, and procurement data for builders, dealers, and developers sourcing entrance doors at wholesale volume. Every door ships with 100% full inspection (not sampling) and CE-certified documentation.

Front Door for House Pricing and Configurations

Standard vs Premium Configuration Pricing

Pricing below covers aluminum front doors for house applications, FOB Foshan, in USD per square meter of door leaf area. Prices include frame, leaf, glass, and standard hardware; premium locks and finishes add the listed premium.

Volume Pricing Tiers and MOQ

Wholesale pricing scales with order quantity. Mixed-model orders (single + double leaf, different sizes) count toward the same tier. Stock-sized doors (900×2100 mm, 1000×2100 mm) ship faster than custom sizes. Custom RAL colors add 5-8 days to lead time for small-batch powder coating setup.

MOQ is 10 sets. Payment terms: 30% T/T deposit, 70% balance before shipment. L/C at sight accepted for orders above 200 sets or USD 50,000. Incoterms: FOB Guangzhou or Shenzhen, CIF main ports, or DDP (available for Southeast Asia and Australia).

Entry Door Material and Profile Specifications

Aluminum Alloy Grades and Wall Thickness

Profiles extrude from 6063-T5 aluminum alloy (chemical composition: Mg 0.45-0.9%, Si 0.2-0.6%, Fe 0.35% max). Wall thickness options by application: 1.4 mm for standard residential, 1.6 mm for thermal-break residential, 1.8 mm for double-leaf, 2.0 mm for commercial and pivot doors. Tensile strength 160 MPa minimum, yield 110 MPa minimum, elongation 8% minimum.

Surface treatments available: electrophoresis (E-Electrophoresis, film 12-15 um), anodizing (AA15, 15 um oxide layer), and powder coating (Akzo Nobel or Tiger Drylac polyester, 60-80 um, 300+ RAL colors plus wood-grain sublimation). Powder coating passes AAMA 2604 salt-spray test at 1000+ hours to white rust. AAMA 2605 (fluorocarbon PVDF) rated at 4000+ hours for coastal projects.

Thermal Break Strip Specifications

Thermal break profiles use polyamide 66 (PA66) reinforced with 25% glass fiber (GF25) strips. Three strip widths: 14.8 mm (standard residential), 24 mm (high-insulation), and 34 mm (passive house grade). A 24 mm strip reduces frame U-value from 5.7 W/m2K (non-thermal) to 2.1 W/m2K. A 34 mm strip reaches 1.4 W/m2K. Each strip cavity receives foam injection to block convective heat transfer. Strip shear strength 80 N/mm minimum per ISO 527.

Entrance Door Performance Ratings

U-Value, Air and Water Tightness Data

Tested per GB/T 7106 (Chinese national standard) and EN 12208/12207/12210 (European). All configurations reach air-tightness Class 4 (0.5 m3/h.m at 100 Pa pressure difference max). Data below applies to a 900×2100 mm single-leaf door.

Wind Load and Impact Resistance

Structural profiles test to GB/T 7106. Wind load ratings: 2.0 kPa (Grade 6), 2.5 kPa (Grade 7), 3.5 kPa (Grade 9). Deflection limit at design pressure: L/180 (where L = span). Impact resistance: tempered glass withstands 1040 g steel-ball drop test from 1200 mm height. For hurricane zones, laminated 6.38 mm + PVB configurations pass Miami-Dade NOA protocols TAS 201 (large-missile impact), TAS 202 (uniform static pressure), and TAS 203 (cyclic wind pressure).

Front Entry Doors Hardware Systems

Multi-point Lock Systems

Standard hardware brands: HOPO, Siegenia, or Roto (German and Chinese sourced). Lock configurations: 3-point (top + middle + bottom shootbolts), 5-point, and 7-point for double-leaf doors. Cylinder: European profile DIN 18252, anti-drill and anti-pick with hardened steel pins. Handles: 304 stainless steel, die-cast zinc with chrome finish, or solid brass. Lock cycle test: 100,000 open/close operations per EN 13126 with 2 Nm operating force maximum.

Hinges, Handles and Thresholds

Hinges: 3D adjustable stainless steel (304 grade), load capacity 80-120 kg per leaf depending on model. Adjustment range: 2 mm vertical, 1 mm horizontal, 1 mm depth. Three hinges per leaf for doors above 90 kg. Thresholds: aluminum with thermal-break insert, step height 20-45 mm, optional accessibility flush threshold at 15 mm. Weatherstripping: EPDM triple-seal gasket, compression set under 25% at 70C for 72 hours, service temperature -40C to +80C.

Modern Front Doors for Houses Production Process

Extrusion, Anodizing and Powder Coating Parameters

Extrusion: billet heating 480-510C, container 420-460C, extrusion speed 15-25 m/min for 6063-T5. Quench: forced air or water mist depending on section complexity. Aging: 175C for 6-8 hours to reach T5 temper. Anodizing line: sulfuric acid bath at 20C, current density 1.2-1.5 A/dm2, duration 40-60 min for AA15. Powder coating: electrostatic spray at 60-80 kV, 180C cure for 15 min. Adhesion: crosshatch Class 0 (ISO 2409), mandrel bend no cracking at 3 mm radius.

Assembly Line and Quality Control

Assembly stations: (1) cutting via double-miter saw, tolerance 0.2 mm; (2) corner crimping at 45 degrees with mechanical crimp plus aluminum corner keys; (3) hardware mounting, torque-checked to 8-10 Nm; (4) dry glazing with EPDM setting blocks at quarter points; (5) air and water pressure test per sample batch. 100% full inspection (not sampling) on every finished door. Each unit logged with 48 QC parameters across 12 checkpoint stations. Test reports archived 5 years per ISO 9001 traceability.

Certifications and Compliance Standards

CE, NFRC and AAMA Certifications

CE marking per EN 14351-1 (windows and doors product standard). NFRC: U-factor and SHGC certified per NFRC 100 (whole product) and NFRC 200 (glass only). AAMA 101 (North America): covers structural performance and air-water-structural ratings. CE Declaration of Performance (DoP) issued per order batch. Third-party test reports from SGS, Intertek, and TUV available on request.

ISO 9001 and Miami-Dade NOA

Factory certified ISO 9001:2015 (quality management) and ISO 14001:2015 (environmental management). Miami-Dade NOA available for hurricane-impact configurations. Australian Standard AS 2047 compliance for the Australian market. Additional test data: acoustic rating Rw up to 36 dB with 6+12A+6mm acoustic laminated glass. PAS 24:2016 enhanced security performance for UK affordable housing available on request.

Procurement, Packaging and Lead Time

MOQ, Payment Terms and Incoterms

MOQ: 10 sets (mixed models and sizes acceptable). Payment: 30% deposit by T/T, 70% balance before B/L copy; L/C at sight for orders above USD 50,000. Incoterms: FOB Guangzhou or Shenzhen, CIF main ports, DDP available for Southeast Asia and Australia. Sample policy: 1 sample at 1.5x unit price, fully refunded on bulk order above MOQ. Sample lead time: 12-15 days.

Packaging Specifications and Container Loading

Packaging: EPE foam corners + corrugated board wrap + wooden crate (fumigated, ISPM-15 stamped). Crate dimensions for single leaf 900×2100 mm: 2.15 m x 1.05 m x 0.18 m, gross weight 28 kg. Container loading: 200 sets per 20GP, 480 sets per 40HQ. Custom packaging, private-label cartons, and buyer-specific labeling available at no extra cost for 100+ set orders.

Installation Guide and Project Case

Installation Steps and Waterproofing

Installation sequence: (1) verify rough opening, tolerance 5 mm each side; (2) place door frame, shim at 6 points minimum; (3) secure with expansion bolts at 400 mm centers, 8mm x 75mm; (4) check plumb and level to 1 mm per meter; (5) inject low-expansion polyurethane foam sealant around frame; (6) apply butyl-rubber flashing tape over frame flange; (7) hang leaf, adjust 3D hinges; (8) test multi-point lock engagement; (9) apply exterior-grade silicone perimeter seal. Waterproofing: apply two coats of waterproof membrane at sill before setting frame. Allow 24-hour cure before final seal.

Project Case: Residential Villa Development, Melbourne

Client: residential developer in Melbourne, Australia. Order: 48 sets thermal-break double-leaf front entry doors. Specification: 1.8 mm wall, 6+12A+6mm DGU, powder-coated RAL 7016 (anthracite grey), 5-point HOPO locks. Unit price: USD 380/m2 FOB. Total project value: USD 52,000. Installed area: 137 m2. Lead time: 32 days ex-factory. Certification: AS 2047 compliant. Energy performance: 38% reduction in HVAC load at the glazing zone compared to the client prior steel-door baseline. The client placed a repeat order for 60 sets four months later, citing finish consistency and zero defect rate on the first shipment.

Comparison: Aluminum vs Steel vs Wood Front Doors

Related products for full project supply: exterior doors, aluminum doors, and aluminum windows.

Contact ROGENILAN for a project-specific quotation with lead time and certification options tailored to your destination market and building code. Technical drawings, cross-section details, and BIM files available for orders above 30 sets.
