Sliding Patio Door Export from China: Aluminum Sliding Glass Doors Specs & Pricing

1. Frame Profiles and Thermal Break Data

6063-T5 Extrusions, 2.0 mm Wall

The sliding patio door frame is extruded from 6063-T5 aluminum billet with a minimum wall thickness of 2.0 mm on structural members (sash rails, meeting stiles, sill track) and 1.4 mm on non-structural trim. Tensile strength is 160 MPa minimum, yield 110 MPa minimum. Sash depth is 100 mm for the 2-track system and 165 mm for the 3-track system; both accept glass from 20 mm to 32 mm overall thickness. Each sliding sash runs on two stainless steel tandem rollers rated at 120 kg per pair, adjustable plus/minus 5 mm in height from the interior face.

Thermal Break and Surface Finishes

The thermal break is a 24 mm PA66 GF25 polyamide strip (glass-fiber reinforced, C-shaped) rolled into the inner and outer extrusions. Frame U-value measured per NFRC 100 is 2.2 W/m2K for the 2-track frame and 2.4 W/m2K for the 3-track frame. Standard finishes: powder coating to AAMA 2604 (60 micron film, 10-year color warranty, RAL or wood-grain sublimation), or PVDF to AAMA 2605 (2-coat, 70 percent Kynar resin) for coastal and high-UV states. Anodized finish at 15-20 micron is available for commercial storefront-adjacent projects.

2. Sliding Glass Doors: Glazing Options and NFRC Ratings

Standard Glazing Build-Ups

All sliding glass doors ship with tempered safety glass to ANSI Z97.1 / CPSC 16 CFR 1201 (Category II) as standard. The three volume build-ups below cover 90 percent of North American orders; center-of-glass values are per NFRC 100/200 simulation with a warm-edge spacer and 90 percent argon fill.

ENERGY STAR Version 7.0 Zone Compliance

ENERGY STAR 7.0 (effective October 2023) requires doors to meet U-factor and SHGC limits that vary by climate zone. A patio door is classed as a door when glazing exceeds 50 percent of the area, which applies to all configurations on this page. The double-silver low-E build-up satisfies the Northern zone; the single-silver build-up satisfies the Southern zone. For the Northern zone, the 0.30 U-factor build-up with SHGC 0.27 passes because the SHGC limit in that zone is 0.40 with a U-factor trade-off path.

3. FOB Price Table by Configuration

Price Bands per Square Meter (FOB Foshan)

Prices below are FOB Foshan/Guangzhou port for the thermal-break system with double glazed low-E glass (5+12A+5), AAMA 2604 powder coat, standard hardware and stainless rollers. Non-standard RAL colors add USD 4/m2; PVDF adds USD 12/m2; wood-grain sublimation adds USD 9/m2. Prices are volume-tiered at 20-100 m2, 100-300 m2 and 300+ m2 per order.

Options and Surcharges

• Retractable insect screen ( fiberglass mesh, aluminum cassette ): USD 28-45 per linear meter of opening width.
• Low-profile ADA sill (12 mm upstand): USD 6/m2.
• Keyed exterior handle + 3-point lock upgrade: USD 14 per sash.
• Laminated glass upgrade (from monolithic tempered): USD 18-24/m2.
• Blinds-between-glass (magnetic, 12.5 mm slat): USD 55-70/m2, adds 8 kg/m2.
• Miami-Dade impact package (laminated IGU + reinforced interlock + NOA paperwork): USD 38-52/m2, see Section 6.

For volume programs above 1,000 m2 per year, pricing follows the wholesale ladder on our sliding door wholesaler page, which also lists regional agent terms. Buyers comparing total door budgets can cross-check against the patio doors wholesale supply page for mixed-container consolidation with French and folding doors.

4. Aluminum Sliding Door Configurations and Track Design

Standard vs Lift-and-Slide Mechanics

The standard aluminum sliding door runs the sash directly on tandem rollers with a brush-seal perimeter; maximum sash weight is 240 kg and maximum sash size is 1.8 x 2.6 m. The lift-and-slide system raises the sash 6 mm onto its rollers when the handle rotates 180 degrees, compressing a continuous EPDM gasket in the closed position. Air infiltration on the lift-and-slide is 0.06 cfm/ft2 at 75 Pa versus 0.15 cfm/ft2 on the standard system, which is why lift-and-slide is the default recommendation north of climate zone 5 and for any sash wider than 1.5 m.

Panel Arrangements by Opening Width

Heavy or oversize sashes (above 240 kg, above 3.0 m height) move to the heavy-duty platform with 3.0 mm wall profiles and quad rollers; see the heavy-duty aluminum sliding doors page for that system’s load tables.

5. Sliding Glass Doors Exterior: Standard North American Sizes

Rough-Opening Chart (Imperial)

Sliding glass doors exterior orders from US and Canadian dealers follow imperial rough openings. The table below maps the six highest-volume call-outs to frame sizes and panel splits. Frame size equals rough opening minus 12 mm on width and 6 mm on height for shim space.

Custom Sizes and Tolerances

Any width from 1.2 m to 12 m and height from 1.9 m to 3.0 m can be produced without tooling charges. Manufacturing tolerance is plus/minus 1.5 mm on frame diagonals. Heights above 2.6 m automatically move to the 2.5 mm wall sash and double-silver low-E is replaced by heat-strengthened laminated on the exterior lite when the glass area per lite exceeds 3.6 m2, per ASTM E1300 load calculations.

6. Patio Sliding Door for Hurricane Zones (HVHZ)

Miami-Dade NOA and Florida Product Approval

For High-Velocity Hurricane Zone counties (Miami-Dade, Broward) the patio sliding door is supplied under a Miami-Dade NOA with the following test evidence: large and small missile impact per TAS 201/203, cyclic wind pressure per TAS 203, and uniform static air per TAS 202. The impact build-up is 8 mm tempered + 16 mm argon + 5+1.52PVB+5 laminated low-E, with a reinforced 3.0 mm interlock and stainless steel anti-lift blocks every 600 mm.

Non-HVHZ Coastal Orders

Outside HVHZ counties, most Gulf and Atlantic coast projects specify DP50 with the standard laminated build-up (5+12A+5 laminated inner) rather than the full NOA package; this keeps the surcharge at USD 18-24/m2 instead of USD 38-52/m2. Texas Windstorm (TDI) jurisdictions accept AAMA 101 DP50 test reports with an engineer’s shop-drawing stamp, which ROGENILAN supplies with the submittal package.

7. Certifications and Lab Test Data

North American Test Reports

• AAMA/WDMA/CSA 101/I.S.2/A440: product type SD, Performance Class R, DP50 and DP65 reports from a Keystone-accredited lab.
• NFRC 100/200: U-factor and SHGC simulations per glazing build-up; NFRC-certified label data available for ENERGY STAR submittals.
• ASTM E283 air infiltration: 0.06 cfm/ft2 (lift-and-slide) / 0.15 cfm/ft2 (standard) at 75 Pa.
• ASTM E547 water penetration: no leakage at 720 Pa cyclic (DP50 frame).
• ASTM E330 structural: 1.5x design pressure overload without permanent set.
• AAMA 2604/2605 coating reports; ISO 9001:2015 factory QMS certificate; CE EN 14351-1 for parallel EU programs.

Submittal Package Contents

Each container ships with: NFRC simulation report per SKU, AAMA 101 test summary, tempered glass certificates (ANSI Z97.1), coating warranty certificates, installation manual (English), shim and fastener schedule, and a spare-parts kit (rollers x4, handle x1, wool pile 5 m) per 100 m2 of door area. Digital submittals are issued within 48 hours of deposit for permit applications.

8. Ordering from China: MOQ, Payment, Packing

MOQ, Lead Time and Payment Terms

Minimum order quantity is 20 m2 of door area, which can be mixed across configurations and finishes in one container. Production lead time is 30-40 days from drawing approval: 12 days for profile extrusion and coating, 10 days for glass processing, 8 days for assembly and QC. Payment is 30 percent T/T deposit against PI, 70 percent against B/L copy; irrevocable L/C at sight is accepted for orders above USD 80,000. FOB Foshan/Guangzhou is standard; CIF quotes to Houston, Los Angeles, New York, Vancouver and Toronto are issued on request.

Packing and Container Loading

9. Installation and Flashing Sequence

Step Sequence (ASTM E2112 Method B)

• 1. Verify rough opening plumb/level within 3 mm over 2.4 m; check diagonal within 4 mm.
• 2. Apply self-adhered flashing membrane to the sill pan, upturned 100 mm at jambs; install sloped sill pan with back dam.
• 3. Set the KD frame on composite shims at 300 mm centers; anchor jambs at 150 mm from corners and 450 mm centers with corrosion-resistant screws.
• 4. Lap jamb flashing over the frame flange, then head flashing; integrate with the WRB in shingle fashion.
• 5. Hang fixed panel first (exterior track), then sliding panel; adjust tandem rollers until the sash reveals are even within 2 mm.
• 6. Backer rod and ASTM C920 Class 25 silicone sealant at the interior perimeter; leave the sill drainage path open.
• 7. Water-test the sill at 2 L/min for 15 minutes before interior trim; adjust the interlock bumpers and verify lock throw.

Commissioning Checks

Sliding force should read 40-60 N at the handle on a 240 kg sash after roller adjustment. Air-seal the meeting stile by compressing the fin-seal bumpers until the interlock gap closes to 4 mm. For lift-and-slide units, cycle the handle 20 times before handover and confirm the sash drops fully onto the gasket; an unseated sash is the number one cause of air-leakage callbacks.

10. Case Study: 48-Home Subdivision in Houston, Texas

Scope and Configuration

A production builder sourced all rear-elevation patio doors for 48 single-family homes in a Houston subdivision. Scope: 48 units of 6-0 x 6-8 OX 2-panel and 96 units of 8-0 x 8-0 OXO 3-panel, thermal-break frames in bronze AAMA 2604 powder coat, single-silver low-E glass with SHGC 0.25 solar-control variant (Southern zone), standard DP50 (non-HVHZ Harris County), retractable screens on all OX units. Total door area: 694 m2 in three 40 HQ containers.

Result and Schedule

Landed cost came to USD 121,900 versus the local dealer quote of USD 289,300, a saving of 57.9 percent. Schedule: drawings approved day 7 after deposit, production 34 days, ocean transit 29 days, customs clearance 4 days. Two sashes arrived with scratched stiles (0.7 percent of panels) and were replaced from the spare-parts allowance plus a couriered replacement within 12 days under the project warranty.

11. Aluminum vs Vinyl vs Wood-Clad Patio Doors

Measured Comparison

When Each Material Wins

Vinyl leads on frame U-value and first cost in mild climates, but its thermal expansion (2.6x aluminum) causes sash binding on wide panels and it cannot be produced beyond 1.2 m sash width. Wood-clad leads on interior aesthetics at 3-5x the landed cost and requires refinishing cycles in humid climates. Thermal-break aluminum is the only option that holds DP50+ at sash widths above 1.5 m, which is why production builders and multi-family projects use it for 8 ft and wider openings. Buyers speccing full window-and-door packages can review the same comparison on the aluminium windows and doors wholesaler page, and for all-glass front elevations the glass door wholesale page covers frameless-adjacent options.
